Edwards STP-iXA4507 Series User Manual

STP-iXA4507 series Turbomolecular Pump
MT-91E-001-0
Page 19
TECHNICAL DATA
2
2.4 External appearance of the STP pump
Figure 9 - External appearance of STP-iXA4507 series
VG300
ISO320F
VG350
VG400
φA
400
425
450
520
φB
420
420
420
420
C
18
20
24.5
20
D
370
360.5
325
315
E
465
455.5
420
410
F
247
237.5
202
192
G
292.5
283
247.5
237.5
H
383.5
374
338.5
328.5
I
349
339.5
304
294
φJ
370
395
420
480
φK
15
14
15
19
No.
Item
Description
1
PU: Pump unit
2
CU: Control unit
AC220V
3
Outlet port flange
KF50
Outlet port pipe
52.2mm (ID)
4
Purge port
KF10
5
Water cooling port
of the PU
9/16-18UNF
6
Water cooling port
of the CU
Tube fitting 1/4”
7
Screw hole for
securing the base
4-M16 depth 25
