Edwards STP-iXA4507 Series User Manual

STP-iXA4507 series Turbomolecular Pump
MT-91E-001-0
Page 105
SERIAL COMMUNICATION PROTOCOL
5
5.4.17 SetOptionFunc
Function: Changing the setting value of the input operation port, TMS option, warning function, serial
communication time out, and PROG OUT/PROG IN.
CAUTION
There is an endurance limit of setting changes (no more than 24 times per day for about ten years).
If this limit is exceeded, it not only may become impossible to change the setting but can also cause
pump failure. Do not make setting changes in excess of this endurance limit.
Transmission frame:
*1
PC->SIM
Stx
0
0
1
Sp
=
Parameter 1 to 15
Etx
LRC
SIM->PC
Ack
PC->SIM
Ack
SIM->PC
Stx
0
0
1
#
Etx
LRC
*1 The HEX code of ASCII character ' = ' is "3D".
Parameter
Item
Data format
Remarks
1
*1
Input operation port setting
8-bits hexadecimal coded
ASCII
Default 01
hex
(I/O Remote)
Default 02
hex
(EtherCAT)
2
*2
TMS Option
Enable/Disable setting
8-bits hexadecimal coded
ASCII
Default FF
hex
(DISABLE)
3
[System reservation]
48-bits hexadecimal
coded ASCII
*3
4
Second Damage Limit Option
Enable/Disable setting
8-bits hexadecimal
coded ASCII
Default 00
hex
(ENABLE)
5
First Damage Limit Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
Default 00
hex
(ENABLE)
6
Pump Runtime Over Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
Default FF
hex
(DISABLE)
7
Pump Runtime Over Warning
Hours setting (×100 hours)
32-bits hexadecimal
coded ASCII
Default
00000000
hex
8
Imbalance Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
Default 00
hex
(ENABLE)
9
Pump Overload Warning
Enable/Disable setting
8-bits hexadecimal
coded ASCII
Default FF
hex
(DISABLE)
