SERIAL COMMUNICATION PROTOCOL
5
5.4.14 ReadModFonctWithWarning
Function: Reading the pump operation mode, errors and warnings being detected.
Transmission Frame:
PC→SIM
Stx
0
0
1
?
m
Etx
LRC
SIM→PC
Ack
PC→SIM
Ack
SIM→PC
Stx
0
0
1
Sp
m
Parameter 1 to 82
*1
Etx
LRC
Parameter
Item
Data format
Remark
1
Pump operation mode
8-bits hexadecimal
coded ASCII
See Table 25
2
WARNING being detected
16-bits hexadecimal
coded ASCII
See Table 28
3
The number of errors detected
8-bits hexadecimal
coded ASCII
Up to 80 errors
*1
4 to 83
*1
Error 1
8-bits hexadecimal
coded ASCII
*2
…
Error 80
*1
8-bits hexadecimal
coded ASCII
*1 The maximum number of errors may differ depending upon the software version of the STP pump. It is recommended that
an application be designed as variable-length data.
*2 The values corresponding to the error message are transmitted (refer to Table 24 and Table 25). The larger parameter
number means the more recent errors. When the number of errors being detected is under the maximum number, the
parameter value larger than the number of errors being detected is set to 0.
