SERIAL COMMUNICATION PROTOCOL
PAG
E
114
5
5.4.20 SetOptions
Function: Changing the setting value of the optional function; the parameter n depends on the
optional function.
Transmission frame:
PC->SIM
Stx
0
0
1
Sp
0
Parameter 1 to n
Etx
LRC
SIM->PC
Ack
PC->SIM
Ack
SIM->PC
Stx
0
0
1
#
Etx
LRC
Parameter
Item
Data format
Remark
1
Optional function number
16-bits hexadecimal
coded ASCII
see Table 30
2 to n
Function item
Optional function number
Value
Total parameter n
Remark
Second speed option setting
0014
3
see 5.4.20.1
Second speed selection
0015
2
see 5.4.20.2
Table 30 - Option function number and parameter list
5.4.20.1 Second speed function setting
Settings for second speed can be changed.
CAUTION
There is an endurance limit of setting changes (no more than 24 times per day for about ten years).
If this limit is exceeded, it not only may become impossible to change the setting but can also cause
pump failure. Do not make setting changes in excess of this endurance limit.
