Page 6
INTRODUCTION
PAG
E
6
1
2. Caution label of Heater removing prohibition and Warning label for hot surface
The pump has TMS heater, which is mentioned in section 3.9.2, “TMS heater”. That is not
removable. Therefore, do not remove that as “Caution label of Heater removing prohibition”
mentioning.
“Warning label for hot surface” instructs operators not to touch the hot surface of the STP
pump. The pump and control unit will become high temperature while the STP pump is in
operation. This label is for warning operators not to get burned their hands.
Figure 2 - Caution label of Heater removing prohibition and Warning label for hot surface
3. Caution label for the high voltage devices
The pump and the control unit are equipped with the high voltage devices. This label is for
warning operators to pay attention to the high voltage devices during an inspection.
Figure 3 - Caution label for the high voltage devices
4. Label for the rotational direction
This label describes the rotational direction of the STP pump. The STP pump rotates in this
direction.
Figure 4 - Label for the rotational direction
