STP-iXA4507 series Turbomolecular Pump
MT-91E-001-0
Page 93
SERIAL COMMUNICATION PROTOCOL
5
Parameter
Item
Data format
Remark
1
Motor temperature
(Unit: ºC)
16-bits hexadecimal
coded ASCII
Example:
Motor temperature: 0014hex = 20 ºC (68 ºF)
Parameter
1
ASCII
0
0
1
4
HEX
30
30
31
34
5.4.10 ReadStatus
Function: Reading various settings; Remote mode, TMS function
Transmission frame:
PC->SIM
Stx
0
0
1
?
f
Etx
LRC
SIM->PC
Ack
PC->SIM
Ack
SIM->PC
Stx
0
0
1
Sp
f
Parameter 1 to 3
Etx
LRC
Parameter
Item
Data format
Remarks
1
Remote mode setting
8-bits hexadecimal
coded ASCII
Refer to Table 27
2
*1
TMS function setting
8-bits hexadecimal
coded ASCII
00
hex
: ENABLE
Excluding 00
hex
: DISABLE
3
[System reservation]
16-bits hexadecimal
coded ASCII
*1 Valid only with TMS specification. When it is not TMS specification, do not set it to "ENABLE".
