SERIAL COMMUNICATION PROTOCOL
PAG
E
106
5
Parameter
Item
Data format
Remarks
10
Pump Overload Warning
Motor current setting
16-bits hexadecimal
coded ASCII
Default 03E8
hex
(100.0%)
11
Pump Overload Warning
Rotational speed setting
16-bits hexadecimal
coded ASCII
Default 0000
hex
(0.0%)
12
Serial communication
time out setting (Unit: sec.)
16-bits hexadecimal
coded ASCII
Default 003C
hex
(60 sec.)
13
PROG OUT pin setting
8-bits hexadecimal
coded ASCII
Default 05
hex
(WARNING)
14
PROG IN pin setting
8-bits hexadecimal
coded ASCII
Default 02
hex
(RESET/2
nd
SPEED EN)
15
[System reservation]
72-bits hexadecimal
coded ASCII
*4
*1 The default value depends on the communication interface mounted on the STP pump ordered.
*2 Valid only with TMS specification.
*3 Assign the parameter value the reading data of ReadOptionFunc (?=) or FFFF32003CFF
hex
.
*4 Assign the parameter value the reading data of ReadOptionFunc (?=) or F
hex
.
Refer to Table 29 for each parameter set value.
The value is not reflected when a parameter is out of a set range.
Example:
1. Input operation port: 01
hex
= I/O Remote (X4)
2. TMS Option: FF
hex
= DISABLE
4. Second Damage Limit Option: 00
hex
= ENABLE
5. First Damage Limit Warning: 00
hex
= ENABLE
6. Pump Runtime Over Warning: FF
hex
= DISABLE
7. Pump Runtime Over Warning hours: 000003E8
hex
= 1,000 (×100 hours)
8. Imbalance Warning: 00
hex
= ENABLE
9. Pump Overload Warning: FF
hex
= DISABLE
10. Pump Overload Warning Motor current: 03E8
hex
= 1,000 (×0.1%)
11. Pump Overload Warning Rotational speed: 0000
hex
= 0 (×0.1%)
12. Serial communication time out: 003C
hex
= 60 sec.
13. PROG OUT pin: 05
hex
= WARNING
14. PROG IN pin: 02
hex
= RESET/2
nd
SPEED EN
Parameter
1
2
3
4
5
ASCII
0
1
F
F
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
*1
0
0
0
0
HEX
30
31
46
46
30
30
30
30
