ESR-Series. User manual
101
Solution:
Remove VLAN2 from gi1/0/1 port:
esr(config)# interface gi 1/0/1
esr(config-if-gi)# switchport general allowed vlan remove 2 untagged
esr(config-if-gi)# no switchport general pvid
8.1.3 Configuration example 2. Enabling VLAN processing in tagged mode
Objective:
Configure gi1/0/1 and gi1/0/2 ports for packet transmission and reception in VLAN 2, VLAN 64, VLAN 2000.
Solution:
Create VLAN 2, VLAN 64, VLAN 2000 on ESR-1000:
esr-1000(config)# vlan 2,64,2000
