Step Description Command Keys
6 Set a period of time for automatic
configuration backup (optional, relevant
only for auto mode)
esr(config-ahchive)# time-period
<TIME>
<TIME> – periodicity of
automatic redundancy of the
configuration, takes the value in
minutes [1..35791394].
Default value: 720 minutes
7 Set the maximum number of locally
saved configuration backups
(optional, relevant for local and both
types)
esr(config-ahchive)# count-backup
<NUM>
<NUM> – set the maximum
number of locally saved
configuration backups. Takes
values in the range of [1..100].
Default value: 1
17.7.2 Configuration example
Objective:
Configure local and remote backup of the router configuration once a day and upon successful configuration
change. Remote copies should be sent to the tftp server 172.16.252.77 in the esr-example subfolder. The
maximum number of local copies is 30.
Solution:
For successful operation of remote configuration archiving, IP connectivity should be established between the
router and the server, permissions for the passage of tftp traffic over the network and saving files on the server
should be configured.
1 Main configuration step:
Switch to the configuration backup mode:
esr# configure
esr(config)# archive
