ESR-Series. User manual
448
Step Description Command Keys
18 Specify VRRP version (optionally). esr(config-if-gi)# vrrp version
<VERSION>
<VERSION> – VRRP version: 2,
3.
19 Set the mode when vrrp IP address
remains in the UP status regardless of
the status of the interface itself.
(optionally)
esr(config-if-gi)# vrrp force-up
20 Specify the delay between the
assignment of MASTER status to ipv6
vrrp and the start of ND messages
distribution (optionally).
esr(config-if-gi)# ipv6 vrrp timers
nd delay <TIME>
<TIME> – time in seconds,
takes values of [1..60].
Default value: 5
21 Specify the period of ND protocol
information update for ipv6 vrrp in
MASTER status (optionally).
esr(config-if-gi)# ipv6 vrrp timers
nd refresh <TIME>
<TIME> – time in seconds,
takes values of [1..65535].
Default value: 5
22 Specify the amount of ND messages
sent in the update period for ipv6 vrrp in
MASTER status (optionally).
esr(config-if-gi)# ipv6 vrrp timers
nd refresh-repeat <NUM>
<NUM> – amount, takes values
of [1..60].
Default value: 0
23 Specify the amount of ND packets
sendings after setting ipv6 vrrp to the
MASTER status (optionally).
esr(config-if-gi)# ipv6 vrrp timers
nd repeat <NUM>
<NUM> – amount, takes values
of [1..60].
Default value: 1
14.1.2 Configuration example 1
Objective:
Establish LAN virtual gateway in VLAN 50 using VRRP. IP address 192.168.1.1 is used as a local virtual
gateway.
