Specify the interface through which the PPPoE connection will be established:
esr(config-pppoe)# interface gigabitethernet 1/0/7
esr(config- pppoe)# enable
To view the tunnel status, use the following command:
esr# show tunnels configuration pppoe 1
To view PPPoE client session counters, use the following command:
esr# show tunnels counters pppoe 1
15.5 Configuring remote access client via PPTP
PPTP ( Point-to-Point Tunneling Protocol) is a point-to-point tunneling protocol that allows establishing secure
connection with a server by creating a special tunnel in a common unsecured network. PPTP encapsulates
PPP frames into IP packets for transmission via global IP network, e.g. the Internet. PPTP may be used for
tunnel establishment between two local area networks. РРТР uses an additional TCP connection for tunnel
handling.
15.5.1 Configuration algorithm
Step Description Command Keys
1 Create a PPTP tunnel and switch to its
configuration mode.
esr(config)# tunnel pptp <INDEX> <INDEX> – tunnel identifier, set
in the range of: [1..10].
2 Specify the description of the
configured tunnel (optionally).
esr(config-pptp)# description
<DESCRIPTION>
<DESCRIPTION> – tunnel
description, set by the string of
up to 255 characters.
3 Specify VRF instance, in which the given
PPTP tunnel will operate (optionally).
esr(config-pptp)# ip vrf forwarding
<VRF>
<VRF> – VRF name, set by the
string of up to 31 characters.
4 Include the PPTP tunnel in a security
zone and configure interaction rules
between zones or disable firewall (see
section Firewall configuration).
esr(config-pptp)# security-zone
<NAME>
<NAME> – security zone name,
set by the string of up to 31
characters.
esr(config-pptp)# ip firewall
disable
5 Set remote IP address for tunnel
installation.
esr(config-pptp)# remote address
<ADDR>
<ADDR> – local gateway IP
address, defined as
AAA.BBB.CCC.DDD where each
part takes values of [0..255].
