8.1.1 Configuration algorithm
Step Description Command Keys
1 Create VLAN esr(config)# vlan <VID> <VID> – VLAN identifier, set in
the range of [2..4094].
It is also possible to create
multiple vlan (comma
separated), vlan range (hyphen
separated) or combined entry
containing commas and
hyphens.
2 Specify vlan name (optionally) esr(config-vlan)# name <vlan-
name>
<vlan-name> – up to 255
characters.
3 Disable monitoring of the status of
interfaces on which processing of the
given VLAN Ethernet frames is allowed
(optional).
esr(config-vlan)# force-up
4 Disable the processing of incoming
untagged Ethernet frames based on the
default VLAN's switching table (VLAN-
ID – 1) (optional).
esr(config-if-gi)# no switchport
forbidden default-vlan
5 Set L2 interface operation mode. esr(config-if-gi)# mode switchport
6 Set the combined mode of the physical
interface.
esr(config-if-gi)# mode hybrid Only for
ESR-1000/1200/1500/1511/17
00
7 Set L2 interface operation mode. esr(config-if-gi)# switchport
access
Only for ESR-10/12V(F)/14VF/
20/21/100/200/3100.
This mode is the default mode
and is not displayed in the
configuration.
esr(config-if-gi)# switchport trunk Only for ESR-10/12V(F)/14VF/
20/21/100/200/3100.
esr(config-gi)# switchport general Only for
ESR-1000/1200/1500/1511/17
00.
This mode is the default mode
and is not displayed in the
configuration.
