Step Description Command Keys
9 Configure a registration server address esr(config-voip-sip-proxy)# ip
address registration-server <IP>
<IP> – registration server IP
address.
10 Configure a registration server port: esr(config-voip-sip-proxy)# ip
portregistration-server <PORT>
<PORT> – number of
registration server UDP port,
takes values of [1..65535]. If
standard 5060 port is used, you
do not need to specify it.
11 Specify SIP domain in which the device
is located
esr(config-sip-profile)# sip-
domain address <ADDRESS>
<ADDRESS> – SIP domain in
which the device is located, set
by ipv4 address or domain
name.
12 Enable the use of SIP domain when
registering
esr(config-sip-profile)# sip-
domain registration enable
13 Configure a SIP profile esr(config)# sip profile <NUM> <NUM> – SIP profile number,
set in the form of a digit from 1
to 5.
14 Assign a dial plan to the current SIP
profile
esr(config-sip-profile)# dialplan
pattern <DNAME>
<DNAME> – name of the dial
plan, set by the string of up to
31 characters.
15 Enable SIP profile esr(config-sip-profile)# enable
19.2 FXS/FXO ports configuration algorithm
Step Description Command Keys
1 Switch to the FXO/FXS ports
configuration mode.
esr(config)# interface voice-port
<NUM>
<NUM> – port number, takes
values of [1..4].
2 Assign a subscriber number reserved
for a telephone port.
esr(config-voice-port-fxs)# sip
user phone <PHONE>
<PHONE> – subscriber number
reserved for a telephone port,
set by the string of up to 50
characters.
3 Assign the user name matched with the
port.
esr-12v(config-voice-port-fxs)#
sip user display-name <LOGIN>
<LOGIN> – user name
displayed in the Display-Name
field, set by the string of up to
31 characters.
