signal will be returned. Also a set of three-digit numbers starting with “1”, the Invite of which will
be sent to 10.110.60.51 IP address and 5060 port, will be returned.
Example 7: (S3 *xx#|#xx#|#xx#|*xx*x+#) – management and the use of VAS.
Local calls inside the device may be required in some cases. If the device’s IP address is not
known or is periodically changed, it is convenient to use the reserved word {local} as the server
address, which means sending the corresponding sequence of digits to the device’s own address.
Example: (123@{local}) – call on number 123 will be locally processed within the device.
19.8 FXO port configuration
Objective:
Add the ability to make a call to PSTN subscriber through the ESR-12V FXO port.
Solution:
Enable FXO port:
esr(config)# interface voice-port 4
Specify FXO port number same as PSTN access prefix:
esr(config-voice-port-fxo)# sip user phone 9
Specify UDP port from which and to which the FXO set will send and receive SIP messages:
esr(config-voice-port-fxo)# sip port 5064
Specify a displayed name:
esr(config-voice-port-fxo)# sip user display-name user-one
Configure login and password for authentication
esr(config-voice-port-fxo)# authentication name login-9
esr(config-voice-port-fxo)# authentication password superpassword
