ESR-Series. User manual
45
Table 18 – Rear panel connectors description
№ Description
1 Main power supply.
2 Place for installation of a redundant power supply.
3 Hot-swappable removable ventilation modules.
4 Earth bonding point of the device.
ESR-1200, ESR-1000 side panels
The side panel layout of ESR-1200, ESR-1000 is depicted in Figures 17 and 18.
Figure 17 – ESR-1200, 1000 right side panel
Figure 18 – ESR-1200, 1000 left side panel
Side panels of the device have air vents for heat removal. Do not block air vents. This may cause the
components to overheat, which may result in device malfunction. For recommendations on device installation,
see section Installation and connection.
2.4.5 ESR-200, ESR-100 design
ESR-100, ESR-200 front panel
The front panel layout of ESR-200 is depicted in figure 19.
Figure 19 – ESR-200 front panel
The front panel layout of ESR-100 is depicted in figure 20.

ELTEX ESR Series Specifications

General

Model	ESR Series
Category	Network Router
Manufacturer	ELTEX
Management	Web interface, CLI, SNMP
Operating Temperature	0°C to 40°C
Dimensions	Varies by model
Weight	Varies by model
Routing Protocols	OSPF, BGP
WAN Interfaces	Ethernet, SFP
LAN Interfaces	Ethernet, SFP
VPN Support	IPsec, L2TP, PPTP
Firewall	Stateful packet inspection, ACLs
Power over Ethernet (PoE)	Available on some models
QoS	Traffic prioritization
