Add gi1/0/1, gi1/0/2 physical interfaces into the created link aggregation group:
esr(config)# interface gigabitethernet 1/0/1-2
esr(config-if-gi)# channel-group 2 mode auto
Further port-channel configuration is performed by analogy to the common physical interface.
8.13 AUX configuration
AUX configuration is used to specify parameters for interacting with external devices connected via serial
interfaces to the ESR.
8.13.1 Configuration algorithm
Step Description Command Keys
1 Switch to the serial interface
configuration mode.
esr(config)# line aux <NUM> <NUM> – a number of a serial
interface from the range [1..3].
2 Set the necessary serial interface
parameters to communicate with the
connected device (optional).
These parameters are usually specified
in the operation manual of the device to
be connected.
By default, the standard values will be
used.
esr(config-line-aux) databits
<BITS>
esr(config-line-aux) flowcontrol
<FMODE>
esr(config-line-aux) parity
<PMODE>
esr(config-line-aux) speed
<SPEED>
esr(config-line-aux) stopbits
<STOP-BITS>
<BITS> – a number of data bits
sent [7..8].
Default is "8",
<FMODE> – data flow control
mode. Takes the following
values:
software – sowtware
flow control;
hardware – hardware
flow control;
disabled – flow control
disabled;
Default is "disabled",
<PMODE> – parity bit setting
mode. Takes the following
values:
For ESR-21.
