ELTEX ESR Series User Manual

ESR-Series. User manual
143
Specify that the interfaces belong to the security zone:
esr-21-2(config)# interface serial 1/0/2
esr-21-2(config-serial)# security-zone xx
esr-21-2(config-serial)# exit
esr-21-2(config)#
Objective 2:
Set up IP connectivity between two ESRs on a Serial port, using Dial-Up modems and the Public Switched
Telephone Network (PSTN)
The ESR-12VF with the following configuration is used as a PSTN emulation:
dialplan pattern factory_test
description "dialplan for factory test"
pattern "S5, L5 (00[1-3]@{local} | [xABCD*#].S)"
enable
exit
sip profile 1
dialplan pattern "factory_test"
enable
proxy primary
enable
ip address proxy-server 192.0.2.5
registration
ip address registration-server 192.0.2.5
exit
exit
interface voice-port 1
sip user phone 001
profile sip 1
exit
interface voice-port 2
sip user phone 002
profile sip 1
caller-id mode fsk-bell
exit
Solution:
Configure the first ESR-21
•
•
Modem compatibility verified
Modem ZyXEL OMNI 56K (MINI)
Modem Acorp-M56SCD

