ELTEX ESR Series User Manual

ESR-Series. User manual
152
Solution:
Pre-configure interfaces on the routers for connection with WAN, enable GRE packets reception from a
security zone where WAN connected interfaces operate.
Create GRE 10 tunnel:
esr(config)# tunnel gre 10
Specify local and remote gateways (IP addresses of WAN border interfaces):
esr(config-gre)# local address 115.0.0.1
esr(config-gre)# remote address 114.0.0.10
Specify tunnel IP address 25.0.0.1/24:
esr(config-gre)# ip address 25.0.0.1/24
Also, the tunnel should belong to the security zone in order to create rules that allow traffic to pass through the
firewall. To define the tunnel inherence to a zone, use the following command:
esr(config-gre)# security-zone untrusted
Enable tunnel:
esr(config-gre)# enable
esr(config-gre)# exit
Create route to the partner's local area network on the router. Specify previously created GRE tunnel as a
destination interface.
esr(config)# ip route 172.16.0.0/16 tunnel gre 10
When settings are applied, traffic will be encapsulated into the tunnel and sent to the partner regardless of
their GRE tunnel existence and settings validity.

ELTEX ESR Series Specifications

General

Model	ESR Series
Category	Network Router
Manufacturer	ELTEX
Management	Web interface, CLI, SNMP
Operating Temperature	0°C to 40°C
Dimensions	Varies by model
Weight	Varies by model
Routing Protocols	OSPF, BGP
WAN Interfaces	Ethernet, SFP
LAN Interfaces	Ethernet, SFP
VPN Support	IPsec, L2TP, PPTP
Firewall	Stateful packet inspection, ACLs
Power over Ethernet (PoE)	Available on some models
QoS	Traffic prioritization
