ELTEX ESR Series User Manual

ESR-Series. User manual
158
2.
esr(config)# security ipsec proposal IPSECPROP
esr(config-ipsec-proposal)# encryption algorithm aes128
esr(config-ipsec-proposal)# exit
esr(config)# security ipsec policy IPSECPOLICY
esr(config-ipsec-policy)# proposal IPSECPROP
esr(config-ipsec-policy)# exit
esr(config)# security ipsec vpn IPSECVPN
esr(config-ipsec-vpn)# mode ike
esr(config-ipsec-vpn)# ike establish-tunnel route
esr(config-ipsec-vpn)# ike gateway IKEGW
esr(config-ipsec-vpn)# ike ipsec-policy IPSECPOLICY
esr(config-ipsec-vpn)# enable
Map IPsec to the GRE tunnel so that clients can establish an encrypted connection:
esr(config-gre)# ip nhrp ipsec IPSECVPN dynamic
Enable NHRP and the tunnel:
esr(config-gre)# ip nhrp enable
esr(config-gre)# enable
Spoke configuration
Perform the standard DMVPN configuration on the tunnel:
esr# configure
esr(config-gre)# tunnel gre 8
esr(config-gre)# mtu 1416
esr(config-gre)# ttl 16
esr(config-gre)# multipoint
esr(config-gre)# local address 180.100.0.10
esr(config-gre)# ip address 10.10.0.8/24
Specify the time while the client record will be stored on the server:
esr(config-gre)# ip nhrp holding-time 300
