ESR-Series. User manual
202
Create IKE protocol profile. Select Diffie-Hellman group 2, 3DES encryption algorithm and SHA1
authentication algorithm in the profile. The given security parameters are used for IKE connection
protection:
esr(config)# security ike proposal IKEPROP
esr(config-ike-proposal)# dh-group 2
esr(config-ike-proposal)# authentication algorithm sha1
esr(config-ike-proposal)# encryption algorithm 3des
esr(config-ike-proposal)# exit
Create IKE protocol policy. For the policy, specify the list of IKE protocol profiles that may be used for
node, authentication key and XAUTH authentication method by key negotiation:
esr(config)# security ike policy IKEPOLICY
esr(config-ike-policy)# pre-shared-key hexadecimal 123FFF
esr(config-ike-policy)# authentication method xauth-psk-key
esr(config-ike-policy)# proposal IKEPROP
esr(config-ike-policy)# exit
Create an access profile and get in it a pair of username and password for the IPsec VPN client:
esr(config)# access profile XAUTH
esr(config-access-profile)# user client1
esr(config-profile)# password ascii-text password123
esr(config-profile)# exit
esr(config-access-profile)# exit
Create a pool of destination addresses from which IP clients will be issued IPsec VPN:
esr-1000(config)# address-assignment pool CLIENT_POOL
esr-1000(config-pool)# ip prefix 192.0.2.0/24
esr-1000(config-pool)# exit
Create IKE protocol gateway. In this profile, you need to specify the IKE protocol policy, the local subnet,
the destination address pool as the remote subnet, set the mode of traffic redirection to the tunnel
according to the policy and use the second authentication factor XAUTH:
esr(config)# security ike gateway IKEGW
esr(config-ike-gw)# ike-policy IKEPOLICY
esr(config-ike-gw)# local address 180.100.0.1
esr(config-ike-gw)# local network 10.0.0.0/16
esr(config-ike-gw)# remote address any
esr(config-ike-gw)# remote network dynamic pool CLIENT_POOL
esr(config-ike-gw)# dead-peer-detection action clear
esr(config-ike-gw)# mode policy-based
esr(config-ike-gw)# xauth access-profile XAUTH
esr(config-ike-gw)# exit
