ESR-Series. User manual
322
PE3(config-ldp)# enable
PE3(config-ldp)# router-id 3.3.3.3
PE3(config-ldp)# address-family ipv4
PE3(config-ldp-af-ipv4)# interface gigabitethernet 1/0/1
PE3(config-ldp-af-ipv4-if)# exit
PE3(config-ldp-af-ipv4)# transport-address 3.3.3.3
PE3(config-ldp-af-ipv4)# exit
PE3(config-ldp)# exit
PE3(config-mpls)# l2vpn
PE3(config-l2vpn)# pw-class for_vpls
PE3(config-l2vpn-pw-class)# exit
PE3(config-l2vpn)# vpls vpls1
PE3(config-l2vpn-vpls)# enable
PE3(config-l2vpn-vpls)# bridge-group 10
PE3(config-l2vpn-vpls)# pw 100 2.2.2.2
PE3(config-l2vpn-pw)# pw-class for_vpls
PE3(config-l2vpn-pw)# enable
PE3(config-l2vpn-pw)# exit
PE3(config-l2vpn-vpls)# pw 100 1.1.1.1
PE3(config-l2vpn-pw)# pw-class for_vpls
PE3(config-l2vpn-pw)# enable
PE3(config-l2vpn-pw)# end
PE3# commit
PE3# confirm
Make sure that the LDP neighborhood is established and display the virtual channel status (pseudowire)
between PE1, PE2 and PE3:
PE3# show mpls ldp neighbor
Peer LDP ID: 1.1.1.1; Local LDP ID 3.3.3.3
State: Operational
TCP connection: 1.1.1.1:646 - 3.3.3.3:45979
Messages sent/received: 22/22
Uptime: 00:13:16
LDP discovery sources:
3.3.3.3 -> 1.1.1.1
Peer LDP ID: 2.2.2.2; Local LDP ID 3.3.3.3
State: Operational
TCP connection: 2.2.2.2:646 - 3.3.3.3:59627
Messages sent/received: 22/22
Uptime: 00:13:20
LDP discovery sources:
3.3.3.3 -> 2.2.2.2
gigabitethernet 1/0/1
PE3# show mpls l2vpn pseudowire
Neighbor PW ID Type Status
--------------------------------------- ---------- ---------- ------
1.1.1.1 100 Ethernet Up
2.2.2.2 100 Ethernet Up
The LDP neighborhood is established, pseudowire has moved to 'UP' status. The l2vpn configuration is now
complete.
