One of the following commands can be used to check the LDP convergence:
ESR1# show mpls ldp neighbor
Peer LDP ID: 2.2.2.2; Local LDP ID 1.1.1.1
State: Operational
TCP connection: 2.2.2.2:33933 - 1.1.1.1:646
Messages sent/received: 1059/1070
Uptime: 17:32:07
LDP discovery sources:
gigabitethernet 1/0/1.10
Peer LDP ID: 4.4.4.4; Local LDP ID 1.1.1.1
State: Operational
TCP connection: 4.4.4.4:40894 - 1.1.1.1:646
Messages sent/received: 1376/1386
Uptime: 22:38:38
LDP discovery sources:
gigabitethernet 1/0/1.40
3 MP-BGP configuration
Create VRF on ESR1 and ESR3, respectively. Specify RD, rt-export/import in accordance with our scheme.
ESR1
ESR1(config)# ip vrf Customer1
ESR1(config-vrf)# ip protocols bgp max-routes 1000
ESR1(config-vrf)# rd 65500:100
ESR1(config-vrf)# route-target import 65500:100
ESR1(config-vrf)# route-target export 65500:100
ESR3
ESR3(config)# ip vrf Customer1
ESR3(config-vrf)# ip protocols bgp max-routes 1000
ESR3(config-vrf)# rd 65500:100
ESR3(config-vrf)# route-target export 65500:100
ESR3(config-vrf)# route-target import 65500:100
ESR3(config-vrf)# exit
Without specifying RD and RT attributes the route information will not get into the VPNv4 table.

