Step Description Command Keys
26 Set destination IP addresses for which
the rule should trigger.
esr(config-ips-category-rule)#
destination-address
{ip <ADDR> | ip-prefix <ADDR/LEN>
| object-group <OBJ_GR_NAME> |
policy-object-group { protect |
external } | any }
<<ADDR> – recepient IP
address, defined as
AAA.BBB.CCC.DDD where each
part takes values of [0..255];
<ADDR/LEN> – recepient IP
subnet, defined as
AAA.BBB.CCC.DDD/EE where
each part AAA-DDD takes
values of [0..255] and LEN
takes values of [1..32].
<OBJ_GR_NAME> – name of IP
addresses profile that contains
recepient IP address, set by the
string of up to 31 characters.
protect – sets recepient
addresses, protect
addresses defined in
IPS/IDS policy;
external – sets external
addresses defined in
IPS/IDS policy as
recepient addresses.
When specifying the “any”
value, the rule will work for any
sender IP address.
27 Set the profile of destination TCP ports
for which the rule should trigger.
Normally TCP port 80 is used for the
http protocol.
In cases where web servers are used on
non-standard ports need to write these
ports too.
esr(config-ips-category-rule)#
destination-port {any | <PORT> |
object-group <OBJ-GR-NAME> }
<PORT> – number of
destination TCP/UDP port,
takes values of [1..65535].
<OBJ_GR_NAME> – recepient
TCP/UDP ports profile name,
set by the string of up to 31
characters.
When specifying the 'any' value,
the rule will be triggered for any
source TCP/UDP port.
28 Set traffic direction for which the rule
should trigger.
esr(config-ips-category-rule)#
direction { one-way | round-trip }
one-way – traffic is
transmitted in one
direction.
round-trip – traffic is
transmitted in both
directions.
29 Define the message that IPS/IDS will
record to the log when this rule will
trigger.
esr(config-ips-category-rule)#
meta log-message <MESSAGE>
<MESSAGE> – text message
specified by a string of up to
129 characters.
