ELTEX ESR Series User Manual

ESR-Series. User manual
456
2 R2 router
hostname R2
interface gigabitethernet 1/0/1
switchport forbidden default-vlan
exit
interface gigabitethernet 1/0/1.741
ip firewall disable
ip address 192.168.0.3/24
vrrp id 10
vrrp ip 192.168.0.1/24
vrrp
exit
interface gigabitethernet 1/0/2
switchport forbidden default-vlan
exit
interface gigabitethernet 1/0/2.742
ip firewall disable
ip address 192.168.1.2/30
exit
interface gigabitethernet 1/0/4
ip firewall disable
ip address 10.0.1.1/24
exit
Solution:
There is no need in any changes in router R2, since subnet 10.0.1.0/24 is terminated on it and as soon as
router R2 is vrrp master, packets will be transmitted to corresponding interface. As soon as R1 becomes vrrp
master, route for packets must be created with destination IP address from network 10.0.1.0/24.
Create tracking-object with corresponding condition:
R1(config)# tracking 1
R1(config-tracking)# vrrp 10 state master
R1(config-tracking)# enable
R1(config-tracking)# exit
Create static route to subnet 10.0.1.0/24 through 192.168.1.2, which will work in case of satisfying of tracking
1 condition:
R1(config)# ip route 10.0.1.0/24 192.168.1.2 track 1
