Step Description Command Keys
10 Specify the profile of services (tcp/udp
ports) {sender | recipient} for which the
rule should work (optionally).
esr(config-dnat-rule)# match [not]
{source|destination}-port <PORT-
SET-NAME>
<PORT-SET-NAME> – port
profile name, set by the string
of up to 31 characters. “Any”
value points at any source
TCP/UDP port.
11 Set name or number of IP for which the
rule should work (optional).
esr(config-dnat-rule)# match [not]
{protocol <TYPE> | protocol-id
<ID> }
<TYPE> – protocol type, takes
the following values: esp, icmp,
ah, eigrp, ospf, igmp, ipip, tcp,
pim, udp, vrrp, rdp, l2tp, gre.
“Any” value points at any
protocol type.
<ID> – IP identification number,
takes values of [0x00-0xFF].
12 Specify the type and code of ICMP
messages for which the rule should
work (if ICMP is selected as protocol)
(optionally).
esr(config-dnat-rule)# match [not]
icmp {<ICMP_TYPE><ICMP_CODE>
| <TYPE-NAME>}
<ICMP_TYPE> – ICMP
message type, takes values of
[0..255].
<ICMP_CODE> – ICMP
message code, takes values of
[0..255]. “Any” value points at
any message code.
<TYPE-NAME> – ICMP
message type name.
13 Specify the action “translation of source
address and port” for the traffic
meeting the requirements of “match”
commands.
esr(config-dnat-rule)# action
destination-nat
{ off | pool <NAME> | netmap
<ADDR/LEN> }
off – translation is disabled;
pool<NAME> – name of the
pool that contains IP addresses
and/or TCP/UDP ports set;
netmap <ADDR/LEN> – subnet
IP address and mask used
during translation. The
parameter is defined as
AAA.BBB.CCC.DDD/EE where
each part AAA-DDD takes
values of [0..255] and EE takes
values of [1..32].
14 Activate a configured rule. esr(config-dnat-rule)# enable
1
When using the not key, the rule will work for values which are not included in a specified profile
Each “match” command may contain “not” key. When using the key, packets that do not meet the given
requirement will fall under the rule.
You can obtain more detail information about router configuration in “CLI command reference guide”.
