ELTEX ESR Series User Manual

ESR-Series. User manual
60
Table 32 – Light indication of copper interface status
SPEED indicator is lit LINK/ACT indicator is lit Ethernet interface state
Off Off The port is disabled or connection is not
established.
Off Solid on 10Mbps or 100Mbps connection is
established.
Solid on Solid on 1000Mbps connection is established.
X Flashes Data transfer is in progress.
Table 33 – Light indication of SFP/SFP+/QSFP+ interface status
RX/ACT indicator is lit TX/ACT indicator is lit Ethernet interface state
Off Off The port is disabled or connection is not
established.
Solid on Solid on Connection established.
Flashes X Data reception in progress.
X Flashes Data transfer is in progress.
The following table lists description of system indicator statuses and meanings.
Table 34 – Status of system indicators
Indicat
or
name
Indicator function LED
State
Device State
Status Current device status LED. Green Device is in normal operation state.
Orange Device is booting up the software.
Alarm Alarm LED. - -
VPN Active VPN sessions
indicator.
- -
Flash Activity indicator of
exchange with data
storages: SD-card or USB
Flash.
Orange Read/write operation execution with 'copy' command.

ELTEX ESR Series Specifications

General

Model	ESR Series
Category	Network Router
Manufacturer	ELTEX
Management	Web interface, CLI, SNMP
Operating Temperature	0°C to 40°C
Dimensions	Varies by model
Weight	Varies by model
Routing Protocols	OSPF, BGP
WAN Interfaces	Ethernet, SFP
LAN Interfaces	Ethernet, SFP
VPN Support	IPsec, L2TP, PPTP
Firewall	Stateful packet inspection, ACLs
Power over Ethernet (PoE)	Available on some models
QoS	Traffic prioritization
