ELTEX ESR Series User Manual

ESR-Series. User manual
89
1.
2.
3.
4.
5.
6.
Firmware update procedure:
When U-Boot finishes the router initialization, break the device startup with the <Esc> key.
Configuring PoE...
distribution 1 dest_threshold 0xa drop_timer 0x0
Configuring POE in bypass mode
NAE configuration done!
initializing port 0, type 2.
initializing port 1, type 2.
SMC Endian Test:b81fb81f
nae-0, nae-1
=======Skip: Load SYS UCORE for old 8xxB1/3xxB0 revision on default.
Hit any key to stop autoboot: 2
Specify TFTP server address:
BRCM.XLP316Lite Rev B0.u-boot# setenv serverip 10.100.100.1
For version 1.5 and newer:
BRCM.XLP316Lite Rev B0.u-boot# serverip10.100.100.2
Specify router IP address:
BRCM.XLP316Lite Rev B0.u-boot# setenv ipaddr 10.100.100.2
For version 1.5 and newer:
BRCM.XLP316Lite Rev B0.u-boot# ipaddr 10.100.100.2
Specify the name of the bootloader file on the TFTP server:
BRCM.XLP316Lite Rev B0.u-boot# uboot_file u-boot.bin
For version 1.5 and newer:
BRCM.XLP316Lite Rev B0.u-boot# uboot_file u-boot.bin
You may save the environment using 'saveenv' command for future updates.
Launch firmware update procedure:
BRCM.XLP316Lite Rev B0.u-boot# run upd_uboot

ELTEX ESR Series Specifications

General

Model	ESR Series
Category	Network Router
Manufacturer	ELTEX
Management	Web interface, CLI, SNMP
Operating Temperature	0°C to 40°C
Dimensions	Varies by model
Weight	Varies by model
Routing Protocols	OSPF, BGP
WAN Interfaces	Ethernet, SFP
LAN Interfaces	Ethernet, SFP
VPN Support	IPsec, L2TP, PPTP
Firewall	Stateful packet inspection, ACLs
Power over Ethernet (PoE)	Available on some models
QoS	Traffic prioritization
