EPSON AcuLaser C1100 Revision B
OPERATING PRINCIPLES Principle of Electric Circuit Operation 118
Figure 2-57. C567MAIN Circuit Block Diagram
Figure 2-58. Circuitry Block Diagram
Panel Specifications 408 panel(with LCD)
Pixel count Specifications PCC+2 external devices
Specified devices UPD617G2-E1-A
SN74AHC2G240HDCT3
PWM Accuracy 6 bit/dot
Device Internal HTC
Plotting method CPGI
Debug environment Connector for serial communication is
on the Controller
Table 2-2. List of Controller Outline Specifications
Item Description
