2.5 Xerographic
This section explains and illustrates the main functional components that consist of the
Xerographic.
 The Xerographic is divided into the following four blocks based on the basic
configuration.
 ROS ASSY
 Photoconductor Unit
 Development
 2nd BTR & FUSER
Figure 2-42. Xerographic Structure
ROS ASSY
Development
Photoconductor Unit
2nd BTR
FUSER
Leg_Sec06_003EB
