EPSON AcuLaser C1100 Revision B
APPENDIX Connectors 511
7.1 Connectors
This section shows the connector locations of EPSON AcuLaser C1100. [P] and [J]
represent “plug” and “jack”, respectively.
7.1.1 The List of Plugs and Jacks
IOT
Table 7-1. IOT
P/J Location Remarks
1 G-156 Connects PWBA FUSER CONT and HARNESS ASSY MAIN
2 G-156 Connects PWBA FUSER CONT and HARNESS ASSY AC
3 G-157 Connects PWBA FUSER CONT and HARNESS ASSY MCU C/L
100 F-122 Connects SWITCH-P/H DOOR and HARNESS ASSY P/H2
101 G-123 Connects SENSOR OHP and HARNESS ASSY P/H2
102 F-123 Connects SENSOR REGI and HARNESS ASSY P/H2
103 D-124 Connects SENSOR PAPER EMPTY and HARNESS ASSY P/H1
104 H-110 Connects SENSOR HUM&TEMP and HARNESS ASSY MAIN
105 D-108
Connects SENSOR ROTARY HOME POSI and HARNESS ASSY
MAIN
106 H-108 Connects ANTENNA CTRG and HARNESS ASSY MAIN
107 D-107 Connects SENSOR IBT RETRACT and HARNESS ASSY MAIN
108 D-106 Connects SENSOR TR-0 and HARNESS-ASSY XERO
109 D-106 Connects ANTENNA ASSY and HARNESS-ASSY XERO
111 G-137 Connects SENSOR FUSER IN and HARNESS ASSY 2BTR SENS
112 H-137 Connects SENSOR 2BTR RETRUCT and HARNESS ASSY ADC
113 H-136
Connects SWITCH 2BTR COVER and HARNESS ASSY 2BTR
SW
114 D-104 Connects SWITCH -INLK FUSER and HARNESS ASSY MAIN
115 G-107 Connects SWITCH-INLK FRONT and HARNESS ASSY MAIN
116 G-108 Connects SWITCH ASSY TOP and HARNESS ASSY MAIN
117 D-105 Connects SWITCH-INLK FUSER and HARNESS ASSY MAIN
125 G-108 Connects SWITCH-FRONT DOOR and HARNESS ASSY MAIN
126 F-138
Connects SENSOR TNER FULL and HARNESS ASSY TNER
FULL
128 G-153 Connects FUSER LOCK SWITCH and HARNESS ASSY MAIN
200 H-153 Connects MOT ASSY P/R and HARNESS ASSY MAIN
201 G-153 Connects MOT ASSY P/R and HARNESS ASSY MAIN
202 F-124 Connects CLUTCH ASSY PRE REGI and HARNESS ASSY P/H2
203 F-122 Connects CLUTCH ASSY REGI and HARNESS ASSY P/H2
204 C-109 For connection inside of MOT ASSY ROT
400 I-149 Connects PWBA MCU and FFC-ASSY ESS
401 I-149 Connects PWBA MCU and FFC-ASSY LV/MCU
403 H-148 Connects PWBA MCU and HARNESS ASSY MAIN
404 H-148 Connects PWBA MCU and MOT ASSY FSR
405 H-148 Connects PWBA MCU and MOT ASSY MAG
406 H-149 Connects PWBA MCU and MOT ASSY MAG
407 H-149 Connects PWBA MCU and HARNESS ASSY MAIN
408 H-148 Connects PWBA MCU and HARNESS ASSY P/H1
409 H-148 Connects PWBA MCU and HARNESS ASSY P/H1
410 I-148 Connects PWBA MCU and HARNESS ASSY MAIN
411 I-148 Connects PWBA MCU and DRIVE ASSY PRO
412 I-148 Connects PWBA MCU and HARNESS ASSY MAIN
413 I-148 Connects PWBA MCU and HARNESS ASSY MAIN
414 I-147 Connects PWBA MCU and DRIVE ASSY PRO
415 J-147 Connects PWBA MCU and HARNESS-ASSY MAIN
416 J-147 Connects PWBA MCU and HARNESS-ASSY XERO
417 I-147 Connects PWBA MCU and HARNESS ASSY MCU C/L
418 I-147 Connects PWBA MCU and HARNESS ASSY ADC
420 J-148 Connects PWBA MCU and HARNESS ASSY MAIN
421 J-148 Connects PWBA MCU and HARNESS ASSY MAIN
422 I-147 Connects PWBA MCU and HARNESS ASSY ADC
429 D-109 Connects PWBA CRUM and HARNESS ASSY MAIN
Table 7-1. IOT
P/J Location Remarks
