EPSON AcuLaser C1100 Revision B
DISASSEMBLY AND ASSEMBLY Overview 281
4.1.4 Tools
Use only specified tools to avoid damaging the printer.
6 For metal
plate Screw
Silver
Metal
plate
• Silver colored
• Uniform screw diameter
7 For metal
plate Screw
Silver with
external
toothed
washer
Metal
plate
• Silver colored
• With external toothed washer
• Uniform screw diameter
Table 4-1. List of screws
No. Type Application Shape How to Recognize Screw Type Cautions
Part,
Metal
Part,
Metal
Name Commercial Availability Code
Phillips screwdriver No.1 Available B743800100
Phillips screwdriver No.2 Available B743800500
Slotted screwdriver Available B743000100
Cutting pliers Available B740400100
Tweezers Available ---
E-Ring holder Available ---
