EPSON AcuLaser C1100 Revision B
APPENDIX Connectors 512
DUP
430 E-109 Connects PWB ASSY ROT and HARNESS ASSY MAIN
431 F-138 Connects SENSOR ASSY ADC and HARNESS ASSY ADC
432 D-109 Connects PWB ASSY ROT and HARNESS ASSY MAIN
433 D-109 Connects PWB ASSY ROT and PWB ASSY MOT
500 H-153 Connects LV/HVPS and FFC-ASSY LV/MCU
501 I-152 Connects LV/HVPS and HARNESS ASSY MAIN
502 I-153 Connects LV/HVPS and HARNESS ASSY MAIN
503 I-155 Connects LV/HVPS and HARNESS ASSY AC
504 H-154 Connects LV/HVPS and WIRE ASSY BTR
505 F-109 Connects LV/HVPS and WIRE ASSY 2BTR
506 E-109 Connects PWBA HVPS and WIRE ASSY IBT
507 E-109 Connects PWBA HVPS and WIRE ASSY DTN
508 H-155 Connects LV/HVPS and WIRE ASSY BCR
509 H-156 Connects LV/HVPS and WIRE ASSY DEVE
510 I-108 Connects HOLDER ASSY BIAS and WIRE ASSY DEVE
512 I-107 Connects GUIDE CRU ASSY AD and WIRE ASSY BTR
513 H-107 Connects GUIDE CRU ASSY AD and WIRE ASSY IBT
514 I-108 Connects GUIDE CRU ASSY AD and WIRE ASSY BCR
515 H-153 Connects LV/HVPS and HARNESS ASSY MAIN
516 F-110 Connects PWBA HVPS and HARNESS ASSY MAIN
600 F-153 Connects MOT ASSY MICRO and HARNESS ASSY MAIN
601 H-138 Connects ROS ASSY and HARNESS ASSY MAIN
602 H-138 Connects ROS ASSY and HARNESS ASSY MAIN
603 F-124 Connects HARNESS ASSY P/H1 and HARNESS ASSY P/H2
604 F-124 Connects MOTOR-PH and HARNESS ASSY P/H1
605 E-124 Connects SOLENOID PICK UP and HARNESS ASSY P/H1
607 E-140 Connects HARNESS ASSY MAIN and HARNESS ASSY DUP2
614 E-105 Connects FUSER ASSY and HARNESS ASSY MCU C/L
617 D-140
Connects HARNESS-ASSY TNER FULL and HARNESS ASSY
MAIN
Table 7-1. IOT
P/J Location Remarks
620 H-137
Connects HARNESS ASSY 2BTR SENS and HARNESS ASSY
ADC
621 I-136 Connects HARNESS ASSY 2BTR SW and HARNESS ASSY ADC
CN1 B-106 Connects OP PANEL and HARNESS ASSY PANEL
CN405 G-155 Connects PWBA ESS and HARNESS ASSY PANEL
CN501 G-156 Connects PWBA ESS and HARNESS ASSY MAIN
CN502 G-155 Connects PWBA ESS and HARNESS ASSY MAIN
CN601 G-155 Connects PWBA ESS and FFC-ASSY ESS
T2 I-107 Connects PLATE BIAS-2ND ASSY and WIRE ASSY 2BTR
T4 H-107 Connects GUIDE CRU ASSY AD and WIRE ASSY DTN
Table 7-2. DUP
P/J Location Remarks
122 G-207 Connects SWITCH-DUP DOOR and HARNESS-ASSY DUP1
123 E-209 Connects SENSOR LOW PASS and HARNESS-ASSY DUP2
124 F-205 Connects SENSOR UPPER PASS and HARNESS-ASSY DUP1
442 H-209 Connects SENSOR UPPER PASS and MOTOR ASSY DUP
443 G-209 Connects PWBA DUP-L and HARNESS-ASSY DUP2
444 H-208 Connects PWBA DUP-L and HARNESS-ASSY DUP1
607 B-209 Connects HARNESS ASSY MAIN and HARNESS-ASSY DUP2
611 D-204 Connects SOLENOID ASSY DUP and HARNESS-ASSY DUP1
612 G-206 Connects MOTOR ASSY DUP INV and HARNESS-ASSY DUP1
Table 7-1. IOT
P/J Location Remarks
