EPSON AcuLaser C1100 Revision B
TROUBLESHOOTING Abnormal Noise-related Trouble 271
17
Is abnormal noise being generated by MOT
ASSY ROT?
Replace MOT
ASSY ROT.
Go to Step [18].
18
Is abnormal noise being generated by
FRAME ASSY-ROTARY that is driven by
MOT ASSY ROT?
Replace
FRAME ASSY-
ROTARY.
Go to Step [19].
19
Is abnormal noise being generated by MOT
ASSY MICRO?
Replace MOT
ASSY MICRO.
Go to Step [20].
20
Is abnormal noise being generated by
FRAME ASSY-2ND that is driven by MOT
ASSY MICRO?
Replace
FRAME ASSY-
2ND.
Go to Step [21].
21
Is abnormal noise being generated by ROS
ASSY?
Replace ROS
ASSY.
Step Check Yes No
