EPSON AcuLaser C1100 Revision B
DISASSEMBLY AND ASSEMBLY TRANSFER 355
REINSTALLATION
1. Match the boss on SENSOR ASSY ADC with the hole on HOLDER-ADC 2ND,
and attach SENSOR ASSY ADC.
2. Fasten SENSOR ASSY ADC to HOLDER-ADC 2ND with the 2 screws (silver,
with washer, tapping, 8 mm).
3. Route the harness in HOLDER-ADC 2ND, match the protrusion on HOLDER-
ADC 2ND with the hole on the main unit, and attach HOLDER-ADC 2ND
together with SENSOR ASSY ADC.
4. Fasten HOLDER-ADC 2ND to the main unit with the 2 screws (silver, with
flange, 8 mm).
5. Connect connector (P/J431) to SENSOR ASSY ADC.
6. Attach FUSER ASSY. (p.388)
7. Attach SPRING-2ND fastening both ends of FRAME ASSY-2ND to the main
unit. (p.346)
8. Attach CAM ASSY-2ND. (p.350)
9. Remove SENSOR 2BTR RETRACT. (p.356)
10. Attach PLATE BIAS-2ND. (p.358)
11. Attach 2ND BTR ASSY. (p.348)
12. Attach CHUTE ASSY-FSR and COVER ASSY-RR 2ND. (p.341)
13. Attach COVER ASSY RH. (p.301)
