EPSON AcuLaser C1100 Revision B
DISASSEMBLY AND ASSEMBLY ELEC 406
Table 4-8. Symptoms when the connector is loose
Connector
No.
Panel Indication Symptom
Error Caused by Connector
Disconnection
P/J400 ---
Printing is not
possible.
---
P/J401 Service Req E537
Printing is not
possible.
Fuser error
P/J403 C Open
Printing is not
possible.
The Cover Fuser is open.
P/J404
Jam C, E, F
Jam E, F
Paper Jam at 2nd
BTR
---
P/J405 ---
Printed light and
faint
---
P/J406 --- Normal printing ---
P/J407 Service Req E510
Printing is not
possible.
ROS Motor error
P/J408 E Open
Printing is not
possible.
Paper Feeder Rear Cover is open.
P/J409 ---
Printing is not
possible.
Sensor TR0 error
P/J410 ---
The printer does
not work
---
P/J411 --- Normal printing ---
P/J412 Service Req E513
Printing is not
possible.
NVM error
P/J413 Service Req E533
Printing is not
possible.
Temperature sensor error
P/J414 ---
Printing is not
possible.
---
P/J415 A Open
Printing is not
possible.
COVER FRONT ASSY U is open.
P/J416
Install
Photocondctr
Printing is not
possible.
IBT Assy error
P/J417 ---
Printing is not
possible.
Fuser error
P/J418 F Open
Printing is not
possible.
Housing Chute Fuser is open.
P/J421 Service Req E547
Printing is not
possible.
Paper Feeder error
P/J422 Service Req E526
Printing is not
possible.
Sensor ADC error
Table 4-8. Symptoms when the connector is loose
Connector
No.
Panel Indication Symptom
Error Caused by Connector
Disconnection
