EPSON AcuLaser M2000D/M2000DN/M2010D/M2010DN Revision B
DISASSEMBLY AND ASSEMBLY Main Unit Disassembly/Reassembly 99
Confidential
DISASSEMBLY FLOWCHART
A5
B6
C6 D6
C1
B1
D1
D2
D3
D4
A1
C2
B2A2
C3
B3A3
C4
B4
C5
B5
D5
A4
Start
Main Motor + Gear Unit
(P. 101)
MP Paper Sensor
(P. 104)
Paper Feed Unit
(P. 103)
Toner Sensor
(P. 104)
Registration Clutch / Paper
Feed Clutch / Developing
Clutch
(P. 102)
Gear Box
(P. 101)
Controller Cover
(P. 100)
Right Cover
(P. 100)
RFID Board
(P. 105)
