4.3 Main Unit Disassembly/Reassembly
4.3.1 Group 1
CONTENT
Parts/Units to be Disassembled
Guide
Toner Cartridge
Front Cover
Rear Cover
Paper Feed Roller (MP Tray)
Controller Cover
A
B
C
D
E
Toner Cartridge
Front Cover
Paper Feed Roller (MP Tray)
A
B
D
Controller Cover
E
Rear Cover
C
