EXTERNAL VIEW AND PART NAMES
Figure 1-1. Front view
Figure 1-2. Rear view
Table 1-1. Part Names
No. Name No. Name
1 Top cover (Cover A) 4 MP tray
2 Control Panel 5 Subtray
3 Standard lower paper cassette 6 Stopper
1
2
3
4
5
6
Table 1-2. Part Names
No. Name No. Name
1 Rear cover 5 USB interface connector
2 AC inlet 6 Network interface connector
3 Power switch 7 Parallel interface connector
4 Option cover
1
2
3
4
5
6
7
5
[Standard model]
[Network model]
