EPSON AcuLaser M2000D/M2000DN/M2010D/M2010DN Revision B
DISASSEMBLY AND ASSEMBLY Main Unit Disassembly/Reassembly 82
Confidential
4.3.3 Group 3
CONTENT
Parts/Units to be Disassembled
Guide
Developing Unit
Photoconductor Unit
Charging Unit
Transfer Roller
A
B
C
D
Developing Unit
Photoconductor Unit
B
A
Charging Unit
C
Photoconductor Unit
Transfer Roller
D
