EPSON AcuLaser M2000D/M2000DN/M2010D/M2010DN Revision B
DISASSEMBLY AND ASSEMBLY Main Unit Disassembly/Reassembly 131
Confidential
4.3.11 Group 11
CONTENT
Parts/Units to be Disassembled
Guide
PF Paper Feed Motor
PF Paper Feed Clutch
PF Paper Conveyance Clutch
A
B
C
PF Paper Feed Motor
A
PF Paper Feed Clutch
PF Paper Conveyance Clutch
CB
