EPSON AcuLaser M2000D/M2000DN/M2010D/M2010DN Revision B
APPENDIX Information Sheet 168
Confidential
7.3.2 Engine Status Sheet
Table 7-2. Engine Status Sheet Information
Location Item Unit Explanation
1 Total Counts Total Pages pages Total number of printed pages
Jam Counts times Number of paper jam
occurrences
2 Toner Cartridge Remain % Remaining amount of toner
Total Dots --- Total number of dots
Changes times Number of detections of new
toner cartridges
Capacity pages Remaining toner capacity
Consumed --- Amount of toner consumption
Pages pages Total number of pages printed
using the cartridge.
3 Maintenance Unit Remain % The current usage level of the
maintenance unit
Pages pages Total number of pages printed
since the unit is installed.
Changes times Number of replacements of
the unit
4 Printer Adjust
Menu
Feed Offset mm The offset values specified
using the printer adjustment
function.
Scan Offset mm
Feed Offset2 mm
Scan Offset2 mm
5 Power On times Number of power-on times
Sleep times Number of times returned
from the power save mode
6 MCU --- Engine controller firmware
version (A 10-digit number)
7 Error Log The following information for each error is printed; panel
messages, EJL status code, the number of printed pages, jam
code, paper size, paper type, date and time. Up to 20 errors are
printed in reverse chronologic order. The target errors are paper
jam errors and service request errors that occurred after “Ready”
status.
 JAM Jam status code is expressed in hexadecimal
eight-digit character string. See “3.4.1 Paper
Jam Error” on page 37 for explanation on
how to read the code.
 Size Paper size indicated on the control panel
 Type Paper type name used to be identified by the
engine
 Date/Time Paper jam occurrence date and time
