EPSON AcuLaser M2000D/M2000DN/M2010D/M2010DN Revision B
DISASSEMBLY AND ASSEMBLY Main Unit Disassembly/Reassembly 113
Confidential
4.3.8 Group 8
CONTENT
Parts/Units to be Disassembled
Guide
Control Panel
Control Panel Board
Top Cover
Left Cooling Fan Motor
A
B
C
D
Control Panel Board
Control Panel
A
B
Top Cover
Left Cooling Fan Motor
C
D
