EPSON AcuLaser M2000D/M2000DN/M2010D/M2010DN Revision B
DISASSEMBLY AND ASSEMBLY Main Unit Disassembly/Reassembly 114
Confidential
DISASSEMBLY FLOWCHART
B4
C5
D6
B1A1
D1C1
D2C2
B2A2
D3C3
D4
D5
C4
B3A3
Start
Control Panel
(P. 116)
Top Cover
(P. 118)
Left Cooling Fan Motor
(P. 118)
Left Cover
(P. 117)
Control Panel Board
(P. 117)
Controller Cover
(P. 115)
Right Cover
(P. 115)
