Epson AcuLaser M2000D - Group 4

EPSON AcuLaser M2000D/M2000DN/M2010D/M2010DN Revision B
DISASSEMBLY AND ASSEMBLY Main Unit Disassembly/Reassembly 87
Confidential
4.3.4 Group 4
CONTENT
Parts/Units to be Disassembled
Guide
Paper Feed Roller (Paper Cassette)
Paper Sensor
Separation Roller (Paper Cassette)
A
B
C
Paper Sensor
Paper Feed Roller (Paper Cassette)
A
B
- Bottom of Main Unit -
Separation Roller (Paper Cassette)
C
