EPSON AcuLaser M2000D/M2000DN/M2010D/M2010DN Revision B
DISASSEMBLY AND ASSEMBLY Main Unit Disassembly/Reassembly 98
Confidential
4.3.6 Group 6
CONTENT
Parts/Units to be Disassembled
Guide
Registration Clutch / Paper Feed Clutch / Developing Clutch
Toner Sensor
MP Paper Sensor
RFID Board
A
B
C
D
Registration Clutch / Paper Feed Clutch
/ Developing Clutch
A
B
C
Toner Sensor
MP Paper Sensor
D
RFID Board
