Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 127
6. Follow the procedure below
a. Downloading files
[Downloading main firmware] (see Avansia User Guide).
Obtain the latest firmware from Evolis website or other sources and download it to the printer.
b. Downloading head resistance value data
Obtain resistance value data for the print head installed in the printer and then download it to the printer.
The print head has an individual serial number stamped on it. Check the serial number and obtain the
resistance value data for the same number.
c. Setting user mode items
Set items to be set under user mode.
For item details, see “Using the Operation Panel”(page 22
).
If you know the settings before replacing the substrate, set the same settings to the new substrate.
d. Setting option connect mode items
Set items to be set under option connect mode.
For item details, see “Using Operation Panel”(page 22
).
If you know the settings before replacing the substrate, set the same settings to the new substrate.
e. Setting and adjustment of service mode items
Set and adjust items to be set under service mode.
For item details, see “Using the Operation Panel"(page 22
).
If you know the settings before replacing the substrate, set the same settings to the new substrate
f. Setting of the printing
Refer to Chapter “Avansia print calibration“ (page 100
).

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
