Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 81
SENSOR CHECK
Sensor Check >
SN01-SN10
Overview
Level indications for sensors (SN1 - SN10)
Detail
Level indications for sensors (SN1 - SN10)
Use Case
At error occurrence
Adj/Set/Operate
Meth
od
Select the item, and then press SET key.
Display/Adj/Set
Range
The
sensor level is displayed on the 2nd line of the LCD in turn from the
left end (bit9).
bit
Parts Name
No.
Status
9
Card Sensor
SN1
0: Card presence
8
Card Sensor (Cleaning Assembly
Outlet)
SN2
1: Block light
7
Card Sensor (Reverse Assembly
Outlet)
SN3
1: Block light
6
Card Sensor [Not used]
SN4
1: Block light
5
Card Edging Sensor (Secondary
Transfer Assembly)
SN5
1: Block light
4
Card Sensor (Ejection Assembly Left)
SN6
1: Block light
3
Reverse Assembly Position Sensor 1
SN7
1: Block light
2
Reverse Assembly Position Sensor 2
SN8
1: Block light
1
Ribbon Beginning Sensor
SN9
1: Block light
0
Ribbon
Feed Length Sensor (Wind Up
Axis)
SN10
1:
Block light
SN11
-SN20
Overview
Level indications for sensors (SN11 - SN20)
Detail
Level indications for sensors (SN11 - SN20)
Use Case
At error occurrence
Adj/Set/Operate
Meth
od
Select the item, and then press SET key.
Display/Adj/Set
Range
The sensor level is displayed on the 2nd line of the LCD in turn from the
left end (bit9).
bit
Parts Name
No.
Status
9
Ribbon
Feed Length Sensor (Supply
Axis)
SN11
0:
Card presence
8
Film Beginning Sensor 1
SN12
1: Block light
7
Film Beginning Sensor 2
SN13
1: Block light
6
Film
Feed Length Sensor (Wind up
Axis)
SN14
1:
Block light
5
Film
Feed Length Sensor (Supply
Axis)
SN15
1:
Block light
4
Platen Position Sensor 1
SN16
1: Block light
3
Platen Position Sensor 2
SN17
1: Block light
2
Heat Roller Position Sensor 1
SN18
1: Block light
1
Decurl Assembly Position Sensor
SN19
1: Block light
0
[Not used]
SN20
1: Block light
SN21-SN26
Overview
Level indications for sensors (SN21 - SN26)
Detail
Level indications for sensors (SN21 - SN26)
Use Case
At error occurrence
Adj/Set/Operate
Meth
od
Select the item, and then press SET key.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
