Service Manual_AVA1_ENG-20220922_I 155
Step 14 – OPTICAL SENSOR (SN2, SN24) – CP011854-CP012327
1. Open the top cover (a) and remove card feeder (b).
2. Open the front cover (a) and the trapdoor cover (b).
b
a
b
a
