Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 88
DM5: Head
Action Check > DM5: Head >
DM5: Up
Overview
Operation check of the Platen Lift Motor (DM5) (move up)
Detail
To operate the Platen Lift Motor (DM5) for the specified period of time (1
to 20
seconds).
The
nip mechanism of the printhead and transfer film feed roller is
moved to the upper position.
Use Case
Checking the operation
Adj/Set/Operate
Meth
- od
Select the item, and then press SET key.
Action Check > DM5: Head >
DM5: Up
Caution
Because the printer becomes operation failure, do not press the SET key
to
stop during operation. If it has been stopped, turn OFF/ON the power
switch.
DM
5:
Home
Overview
Operation check of the Platen Lift Motor (DM5) (home position)
Detail
To
operate the Platen Lift Motor (DM5) for the specified period of time (1
to 20
seconds).
The
nip mechanism of the printhead and transfer film feed roller is
moved to the home position.
Use Case
Checking the operation
Adj/Set/Operate
Meth
- od
Select the item, and then press SET key.
Caution
Because the printer becomes operation failure, do not press the SET key
to
stop during operation. If it has been stopped, turn OFF/ON the power
switch.
DM5:
Down
Overview
Operation check of the Platen Lift Motor (DM5) (move down)
Detail
To operate the Platen Lift Motor (DM5) for the specified period of time (1
to 20
seconds).
The
nip mechanism of the printhead and transfer film feed roller is
moved to the lower position.
Use Case
Checking the operation
Adj/Set/Operate
Meth
- od
Select the item, and then press SET key.
Caution
Because the printer becomes operation failure, do not press the SET key
to
stop during operation. If it has been stopped, turn OFF/ON the power
switch.

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
