Evolis Avansia Service Manual

Service Manual_AVA1_ENG-20220922_I 98
SPARES PART LIST
Product
Code
Product Description Step Page
S10143
PRINT HEAD
16
174
S10195
MAIN BOARD
7
123
S10196
POWER SUPPLY
8
128
S10197
CLEANING ROLLER STATION
11
145
S10198
CLEANING TAPE CASSETTE
*
*
S10199
TRANSFER FILM CASSETTE
*
*
S10200
INK RIBBON CASSETTE
*
*
S10201
CARD FEEDER
*
*
S10202
OUTPUT CARD HOPPER
*
*
S10203
TOP BLACK COVER
6
121
S10204
REAR BLACK COVER
1
110
S10205
PACKAGING: BOX AND FOAM
*
*
CI010222
REJECT BOX
*
*
CP011689
LCD MAIN BOARD
*
*
CP011751
INLET NOISE FILTER
*
*
CP011776
FEEDER FOAM
*
*
CP011777
DUST FILTER
*
*
CP011778
DAMPER, TOP COVER
*
*
CP011779
SHUTTER SPRING
*
*
CP011780
MICRO SWITCH CABLE
*
*
CP011782
LCD FOR OPERATION PANEL
*
*
CP011783
FACE COVER
*
*
CP011784
REAR TOP COVER
2
111
CP011785
REAR SIDE COVER: LEFT
3
113
CP011786
REAR SIDE COVER: RIGHT
3
113
CP011787
FRONT SIDE COVER: LEFT
4
96
CP012516
FRONT SIDE COVER: RIGHT
5
98
CP011789
FILTER COVER
*
*
CP011848
PCB ASSY SHORT SENSOR (SN13)
*
*
CP011849
PULSE MOTOR (HB1 HB2)
*
*
CP011850
DC MOTOR (DM1 DM3 DM7)
*
*
CP011851
DC MOTOR 2 (DM2 DM4)
*
*
CP011852
DC MOTOR 3 (DM5 DM6)
*
*
CP011853
PULSE MOTOR 2 (PM1 PM2 PM3)
*
*
CP011854
OPTICAL SENSOR 2 (SN2 SN3 SN4 SN6 SN23 SN24)
13/14
150/155
CP011855
OPTICAL SENSOR 3(SN1, SN7,SN8,SN10,SN15,SN16,SN17,SN18,SN19,SN25)
*
*
S10248
HEAT ROLLER MODULE
9
130
CP011845
HEAT ROLLER
10
137
CP011846
CASSETTE GUIDE
*
*
CP011847
OPTICAL SENSOR (SN5 SN9 SN12)
12
147
CP011976
DECURL MODULE
15
161
CP013186
FAN 2
*

Evolis Avansia Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Polycarbonate, PVC, PVC Composite
Print technology	Dye-sublimation/Resin Thermal transfer
Print speed (color)	144 card/h
Card thickness (min)	0.76 mm
Duplex print speed (color)	96 card/h
Display	LCD
Lamination	-
Certification	CE, FCC, UL, IEC RoHS
Product color	Black, White
Internal memory	64 MB
Cable lock slot type	Kensington
Total input capacity	250 sheets
Wi-Fi	No
Security algorithms	IPSEC
Ethernet interface type	Fast Ethernet
Bundled software	cardPresso XXS
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	297 mm
Width	340 mm
Height	436 mm
Weight	20000 g
